1137 Fan Powered Humidifier

Search Results for

    Select a diagram to view its parts

    Parts

    Diagram

    Parts
    1
    2
    3
    4
    5
    6
    7
    8
    9
    10
    11
    12
    13
    14
    15
    16
    20
    21
    24
    25
    26
    27

    Parts

    1. 1
      Fan Guard
      Fan Guard
      SKU: 113720
      $17.13
    2. 2
      Fan Blade
      Fan Blade
      SKU: 11379
      $25.72
    3. 3
      Fan Shroud
      Fan Shroud
      SKU: 11372
      $49.06
    4. 4
      Distributor Tube
      Distributor Tube
      SKU: 113724
      $22.04
    5. 5
      Thumbnut
      Thumbnut
      SKU: 10999
      $2.90
    6. 6
      Trough Cover Assembly
      $18.36
    7. 7
      Distributor Trough
      $41.69
    8. 8
      Evaporator Pad
      Evaporator Pad
      SKU: 99013
      $29.46
    9. 8
      Tune UP Kit
      Tune UP Kit
      SKU: 1137MAINTKIT
      $69.86
    10. 9
      Wiring Bracket
      Wiring Bracket
      SKU: 11377
      $10.99
    11. 10
      Speed Nut
      Speed Nut
      SKU: 407
    12. 11
      Relay Circuit Board
      $93.31
    13. 12
      Front Cover Assembly
      $50.28
    14. 13
      Power Supply Cord
      $22.04
    15. 14
      Drain Pan
      Drain Pan
      SKU: 11373
      $44.15
    16. 15
      Hose Clamp
      Hose Clamp
      SKU: P163
      $1.09
    17. 16
      Drain Tube
      Drain Tube
      SKU: 109916
      $29.41
    18. 20
      Orifice And Strainer Assembly
      Orifice And Strainer Assembly
      SKU: 9903776
      $11.04
    19. 20
      Orifice And Strainer Assembly
      Orifice And Strainer Assembly
      SKU: 9903775
      $11.04
    20. 21
      Connector Fittings
      Connector Fittings
      SKU: P103104111
      $3.64
    21. 24
      Cabinet Assembly
      Cabinet Assembly
      SKU: 113738
      $133.79
    22. 24
      Cover Kit
      Cover Kit
      SKU: 1137COVERKIT
    23. 25
      Solenoid Valve Assembly 24V
      $111.73
    24. 25
      Solenoid Valve 115 / 120 Volt
      Solenoid Valve 115 / 120 Volt
      SKU: 113717
      $141.15
    25. 26
      Fan Motor
      Fan Motor
      SKU: 11378
      $163.30
    26. 27
      Cooling Fan
      Cooling Fan
      SKU: 113750
      $14.67

    Parts Not In Diagram

    1. Not Shown
      Mounting Stud
      Mounting Stud
      SKU: 113715
      $1.18
    2. Not Shown
      Fan Motor Grommet
      Fan Motor Grommet
      SKU: 113749
      (Substitute part number)
      $1.31
    3. Not Shown
      Lead Wire Assembly
      $13.45
    4. Not Shown
      Parts Bag
      Parts Bag
      SKU: 113723
      $41.69
